ANTI RADAR CAMOUFLAGE NETS

---

 The specifications of Multi Spectral Camouflage Nets can be customized as per your requirement. Following are the general specifications for your reference:

Size & Shape: Customized
Pattern: Incised, 3D, 2D
Colour Combination: Matching the terrain:Sand, Dark Brown, Light Olive Green, Dark Olive Green or as specified
Finish: Matte finish to avoid reflections, As per IS: 13360 2001 (Part 9:Sec 7) Reaffirmed 2007 At 60 degree incident light < 5 GU
Combustibility: Self-Extinguishing within 10 Sec, as per BS: 3119 & 5438
Weight: 250 gsm+ 5%; as per IS:7016 Pt - I
Heat and Cold Resistance:  - 30 to + 70 degree Celsius

Protection Bands
Visual Range: Wavelength covered 400nm - 750nm
Near Infra-Red Range (NIR): Wavelength covered 750nm - 1200nm (NIR reflectance: Customized)
Thermal Infra-Red Range (TIR): 3000nm - 5000nm & 8000nm - 12000nm

Radar Range: 2-100 Ghz

Radar Attenuation: The MSCN can attenuate the average radar transmission in the centimeter and millimeter wavelength bands above 6 dB, 3 dB one way. The average reduction shall be up to 90%, in accordance with 4.4.2.4 of MIL-PRF-53134

General Properties: Resistant to damage from micro-organisms; Resistant to damage from oils, lubricants, greases & hydrocarbons; Resistant to water and moisture; UV Stabilized; Non-Toxic; Weather proof

Construction: Single layer/Double layer/2D/3D
Garnishing Fabric: BS: >1000 N; as per IS: 7016 Pt - II, TS: >100 N; as per IS: 7016 Pt - III (Method - A, tongue tear method)
Supporting Cordage: Mesh Cord BS: > 450 N; as per IS: 7071 Pt - 4, Edge Cord/Tie Cord BS:>2000 N; as per IS: 7071 Pt - 4
Wash-ability: MSCNs are easily washable using off shelf mild detergents
Life Span: Storage: 7 years (Standard warehouse Storage Conditions), Operation:  < 5 years
Wind tolerance: Withstands high altitude and high speed winds up-to 40-50kmph
